FC6A S
ERIES
MICROS
MART
L
ADDER
P
ROGRAMMING
M
ANUAL
FC9Y-B1726 12-21
12: D
ISPLAY
I
NSTRUCTIONS
Operation Example
To display the 4-digit current value of counter C010 on a 7-segment display (IDEC DD3S-F31N) connected to the transistor sink
output module.
Output Wiring Diagram
When input I0 is on, the 4-digit current value of counter C10
is displayed on 7-segment digital display units.
DATLAT
HL
S1
C10
Q
Q30
DISP
BCD4
(+)
(–)
LATCH
A
B
C
D
(+)
(–)
LATCH
A
B
C
D
(+)
(–)
LATCH
A
B
C
D
(+)
(–)
LATCH
A
B
C
D
(+)
(–)
24V DC
Power
Supply
Q30
Q31
Q32
Q33
Q34
Q35
Q36
Q37
COM
(–)
+
V
8-Transistor Sink
Output Module
(FC6A-T08K1)
10
1
10
0
10
3
10
2
