FC6A S ERIES MICROS MART L ADDER P ROGRAMMING M ANUAL FC9Y-B1726 18-63
18: P ULSE O UTPUT I NSTRUCTIONS
When outputting pulses as shown in the diagram below with the frequency change function (single-pulse output
reversible control disabled) using the following settings
The pulses are output from Q0.
Step 1
100 kHz
10 kHz
5 kHz
15 Hz
Frequency change time
5,000 ms
Preset value 100,000
50 kHz
Step 2
Step 3 Step 4 Step 5
Frequency change time
5,000 ms
Preset value 100,000
Frequency change time
8,000 ms
Frequency change time
8,000 ms
Frequency change time
8,000 ms
Preset value 1,000,000 Preset value 100,000
Interrupt Step
Preset value 30,000Preset value 30,000Preset value 30,000
Frequency Frequency
change timechange time
5,000 ms
5,000 ms
Frequency
change time
5,000 ms
Preset value 1,000,000Preset value 1,000,000Preset value 1,000,000
When the ARAMP instruction input (I0) turns on, pulse
output starts
When I1 turns on, the interrupt input (M0100) is turned on
and the interrupt step is executed
When I2 turns on, the initialization input (M0000) is turned
on and the ARAMP instruction control register values are
initialized
M0000
M0100
I0002
I0000
D2
M0060
D1
D0023
ARAMP
1
S3
M0100
S2
M0000
S1
D0000
I0001
