IDEC MICROSmart FC6A Series Ladder Programming Manual

26: S CRIPT
26-6 FC6A S ERIES MICROS MART L ADDER P ROGRAMMING M ANUAL FC9Y-B1726
4. Enter Script Name.
The script name can be entered up to 40 single-byte alphanumeric characters.
However, the following single-byte characters cannot be used:
/ \:*?"<>|
5. Select Data Type.
Note: The script is executed with the selected data type.
6. In Script, write the program.
Note: To create a script using the sample codes provided by WindLDR, under Function list, select Category and Function, and then click Insert
Format. The sample code displayed in Format is inserted at the cursor position in Script.
7. After you finish creating the script, click OK.
You are returned to the Script Manager dialog box and the created script is displayed in List of scripts.
8. Click Close.
A save confirmation message is displayed.
9. Click OK.
The script is saved and the Script Manager dialog box is closed.
Notes:
• If you click No, the script is not saved and the Script Manager dialog box is closed.
• Script Manager can also be opened from the SCRPT (Script) dialog box.
Click Refer to open Script Manager.
