IDEC MICROSmart FC6A Series Ladder Programming Manual

2: D EVICES
2-44 FC6A S ERIES MICROS MART L ADDER P ROGRAMMING M ANUAL FC9Y-B1726
The system software version displays the version of the software written to the device.
For details on the type ID and status, see "List of Type IDs and Status" on page 2-46.
■ D8618: Refresh Time of Expansion Interface Remote Master/Slave Modules Current Value
The current value of the I/O refresh time of the expansion modules connected with the expansion interface remote master/slave
modules is stored in increments of 1 ms.
■ D8619: Refresh Time of Expansion Interface Remote Master/Slave Modules Maximum Value
The maximum value of the I/O refresh time of the expansion modules connected with the expansion interface remote master/
slave modules is stored in increments of 1 ms.
■ D8630: CPU Module Ethernet Port 2 IP Settings/DNS Settings Switching
The IP settings/DNS settings for Ethernet Port 2 can be changed by writing one of the setting values in the following table to
D8630 and then turning on M8333.
To use this function, enable Enable D8630 (IP Settings / DNS Settings switching) on Ethernet Port 2 in Function Area
Settings of WindLDR.
The meanings of the setting values are as follows.
■ D8631 to D8634: CPU Module Ethernet Port 2 IP Address (Write-only)
These registers are used to write the IP address of Ethernet port 2 on the Plus CPU module.
IP address: To set as aaa.bbb.ccc.ddd, write the following.
D8631 = aaa, D8632 = bbb, D8633 = ccc, D8634 = ddd
■ D8635 to D8638: CPU Module Ethernet Port 2 Subnet Mask (Write-only)
These registers are used to write the subnet mask of Ethernet port 2 on the Plus CPU module.
Subnet mask: For aaa.bbb.ccc.ddd, write the following.
D8635 = aaa, D8636 = bbb, D8637 = ccc, D8638 = ddd
Upper Lower
D8598, D8599 = Expansion Interface Remote Slave Module (Unit 1) Slot Information
D8600, D8601 = Expansion Interface Remote Slave Module (Unit 2) Slot Information
D8602, D8603 = Expansion Interface Remote Slave Module (Unit 3) Slot Information
D8604, D8605 = Expansion Interface Remote Slave Module (Unit 4) Slot Information
D8606, D8607 = Expansion Interface Remote Slave Module (Unit 5) Slot Information
D8608, D8609 = Expansion Interface Remote Slave Module (Unit 6) Slot Information
D8610, D8611 = Expansion Interface Remote Slave Module (Unit 7) Slot Information
D8612, D8613 = Expansion Interface Remote Slave Module (Unit 8) Slot Information
D8614, D8615 = Expansion Interface Remote Slave Module (Unit 9) Slot Information
D8616, D8617 = Expansion Interface Remote Slave Module (Unit 10) Slot Information
Status
Type ID
Upper
Expansion Module Connection Information
System Software Version
Lower
Reserved Number of Connected
Expansion Modules
(0 to 15)
Bit
15
Bit
0
Bit
7
Bit
8
12 34 5 6 910 1112 13 14
Setting Value IP Settings/DNS Settings
0 Conform to function area settings.
1Enable DHCP.
2 Conform to special data register (D8631 to D8650) settings.
