50 Chapter 3 Welder Operation Description
Ehave Series Full Digital IGBT CO
2
/MAG/MMA Multifunctional Inverter Welder User Manual
Job No.
Figure 3-26 Entering the original password
 Note:
The initial password set before delivery is 000000. After it is changed, use the new password as the
original password.
3. If the original password is entered correctly, the screens display 1 good. See Figure 3-27.
The screens flash and the UI for entering a new password is displayed.
Job No.
Figure 3-27 Message indicating that the original password is entered correctly
If the original password is not entered correctly, the screens display o FAIL. See Figure 3-28.
The UI for entering the original password is displayed.
Job No.
Figure 3-28 Message indicating that the original password is not entered correctly
4. On the UI for entering a new password, the first screen displays 1, and the middle and
right screens display -. See Figure 3-29. Use the knob on the control panel to enter a
6-character new password and press the LOAD button.
Job No.
Figure 3-29 Entering a new password
5. After the new password is entered correctly, the screens display 2 good. See Figure 3-30.
The UI for confirming the new password is displayed.
Job No.
Figure 3-30 Message indicating that a new password is entered correctly
6. On the UI for confirming the new password, the first screen displays 2, and the middle
and right screens display -. See Figure 3-31. Use the knob on the control panel to enter
the 6-character new password and press the LOAD button.
