IGS BAOHUI HYPER CROSS - Air Spring Test; Force Feedback Test

36
Using the Operator Settings
4.3.11 Air Spring Test
On the page of ȞAir Spring Testȟ, you can test whether the air spring is functioning
normally or not.
ɖ Enter ȞMain MenuȟɚȞ1 Hardware TestȟɚȞ$LU6SULQJ7HVWȟ, and the screen
will display as below:
ɖ Move the cursor and then press theȞStartȟbutton to test the air spring on the selected
option.
ɖ While testing, you can press theȞStartȟbutton to stop testing at any time.
ɖ Move the cursor toȞ([LWȟ, and press theȞStartȟbutton to return toȞ1
Hardware Testȟ.
4.3.12 Force Feedback Test
On the page of ȞForce Feedback Testȟ, you can test whether the force feedback is
functioning normally or not.
ɖ Enter ȞMain MenuȟɚȞ1 Hardware TestȟɚȞ)RUFH)HHGEDFN7HVWȟ, and the
screen will display as below:
ɖ Use the ȞUpȟ button and the ȞDownȟbutton to move the cursorˈthen press theȞStartȟ
button to run testing.
Hardware Test
