72
Maintenance and Repair
Replacing Parts
5.3.11 Maintenance instructions for the airbag solenoid valve
Remove the fixing screws
from platform maintenance
upper cover and remove
the upper cover carefully.
Platform
maintenance
upper cover
Remove water vapor cover,
and remove the screws
that lock the solenoid valve
in place. After unplugging
pneumatic tube, the solenoid
valve may be taken down for
maintenance.
Water
vapor
cover
Solenoid valve
