IGS BAOHUI HYPER CROSS - Maintenance Instructions for the Air Vent Blowers

65
Maintenance and Repair
Replacing Parts
5.3.5 Maintenance instructions for the air vent blowers
Remove the acrylic on the
air vent according to the
diagram.
Acrylic on the air vent
Remove the blower fixing
frame.
Remove and replace the
blowers according to the
diagram, once completed,
reinstall by reversing the
steps.
