Maintenance and Repair
Replacing Parts
5.3.17 Maintenance instructions for Vehicle IO board and throttle twist grip
Remove the fixing screws of
the acrylic cover according to
diagram.
ɖ Throttle twist grip sensor
(open the vehicle from right
side)
ɖ I/O board maintenance
(both sides are doable)
Remove the fixing screws of
the light box module according
to the diagram, and unplug
the connector carefully.
