IGS BAOHUI HYPER CROSS - Page 98

95
Maintenance and Repair
Replacing Parts
Remove the fixing screws from
the sensor bracket according
to the diagram and begin
maintenance of the throttle twist
grip sensor.
Throttle twist grip
sensor
5HPRYHWKH¿[LQJVFUHZVIURP
the sensor bracket according
to the diagram and begin
maintenance of the throttle
lever. (Identify the right and
left throttle lever sensor by the
marks on the wires.)
Throttle lever sensor
Remove the fixing screws
from the I/O board according
to the diagram and begin
maintenance of the MU and NP
board.
,2¿[LQJERDUG
