63
Maintenance and Repair
Replacing Parts
5.3.4 Maintenance instructions for the screen
Open the rear maintenance
door with the corresponding
key and detach the screen
cables.
Rear
maintenance
door
Remove the screen frame
¿[LQJVFUHZV
Remove the screen frame back
FRYHU¿[LQJVFUHZV
