IGS BAOHUI HYPER CROSS - Explosion Diagrams of the Vehicle

73
Maintenance and Repair
Replacing Parts
5.3.12 Explosion diagrams of the vehicle
2
3
1
5 6 4
8
7
10 11 9 12
15
14
13
17 18 16 13
22
21
20
19
26
27
28
5
23 24 25
PARTS LIST
ITEM TITLE PART NUMBER QTY
5 9
6 16
7 1
8 1
9
10 1
11 1
12 1
13 22
14 7
15
track light board
1
PCB
1 1
2 8
3 1
4 1
8
steering handle bar cover - A AMA-20-31610
vibration speaker NFS_SPEAKER-4INCH
reflective PVC AMA-20-11118-PVC
tail light bracket AMA-20-31820
tail light acrylic AMA-20-31810
AMA-20-31210vibration speaker fixing plate
AMA-20-31710track light board fixing plate
Screw M4X12L SCR_THSHS-N-M4X12L
steering handle bar cover - B AMA-20-31620
Screw M4X15L SCR_THSHS-N-M4X15L
LED Light Strip 100mm LED-100MM
LED Light Strip 50mm LED-50MM
Nut M4 NYLON_NUT-M4
SCR_THS-N-M3X5LScrew M3X5L
PARTS LIST
ITEM TITLE PART NUMBER QTY
16 2
17 1
18 2
19 8
20 8
21 1
22 1
23 4
24
sensor bracket
3
AMA-20-31410
25 2
26 2
MU base board fixing plate AMA-20-31910
sensor LJC18A3-B-Z-BX
Screw M4X20L SCR_PHS-NC-M4X20L
AMA-20-31920MU base board
LJC18A3-B-Z-BX-NUTsensor nut
27 1
MU - LED control panel MU-1191-00
LED driver board NP-1249-00
Screw A3X8L SCR_FLAT-A3X8L
Circuit board L standoff fixed
clips
L_TYPE
SCR_PHS-NC-M4X12LScrew M4X12L
228
SCR_PHS-NC-M5X15LScrew M5X15L
SCR_THS-N-M4X10LScrew M4X10L
