IGS BAOHUI HYPER CROSS - Page 70

67
Maintenance and Repair
Replacing Parts
5.3.7 0DLQWHQDQFHLQVWUXFWLRQVIRUWKHOHIWVLGHDQGULJKWVLGHJXLGHOLJKWERDUGV
Remove the fixing screws
from the bass speaker and
remove the bass speaker
mesh carefully.
Maintenance
door
Remove the fixing hardware
RIWKHOHIWVLGHDQGULJKW
side guide lights sheet metal
according to the diagram.
Remove the light strip fixing
screws according to the
diagram and then begin
maintenance.
Light strip
