5.2.3 Replacing the boost button and the light plate
5.2.4 Replacing the side light plate
1
Remove 4 M5 inner hex
screws and disassemble
the shift lever.
Gear stick
Boost button acrylic
Boost button
Boost meter light plate
2
Remove 4 M4 inner hex
screws and disassemble
the acrylic plate behind
the boost button.
3
Remove 2 M3 cruciform
screws and disassemble
the LED light plate behind
the boost button.
4
Replace the boost button/
the light plate.
5
When done, reassemble
according to the reversed
assembly sequence.
1
Remove 4 inner hex
screws and open the
caps.
Side acrylic cover
Side acrylic
Side light plate
2
Remove 4 M4 screws
and disassemble the
acrylic plate on the left
and right side.
3
Remove 3 M3 cruciform
screws and replace the
LED light plate.
4
When done, reassemble
according to the reversed
assembly sequence.
