5.2.9 Replacing the speaker behind the seat
5.2.10 Replacing the bottom seat back light
1
Remove 6 plastic screws
and take off the cover.
Speaker
Speaker
2
Remove 8 M4 cruciform
screws and replace the
loudspeakers.
3
When done, reassemble
according to the reversed
assembly sequence.
1
Remove 6 plastic screws
and open the cover.
Seat cover
Bottom seat
back light cover
Speaker cover cap
LED light
2
Remove 4 M4 inner hex
screws and take off the
cap of the light.
3
Remove 3 M4 screws
and the decorative cover
of the loudspeaker to
replace the light strip (the
end should be applied
with hot melt adhesive).
4
When done, reassemble
according to the reversed
assembly sequence.
