5.2.17 Maintaining the E3100
5.2.18 Maintaining the full-range AMP
Remove 2 M4 cruciform
screws and take out the
full-range AMP.
Remove 2 M4 cruciform
screws and replace 24W
AMP.
When done, reassemble
according to the reversed
assembly sequence.
1
2
3
Full-range AMP
24
1
Remove 2 M4 butter y
screws.
E3100 holder
2
Take out the xed set to
maintain or repair.
3
When done, reassemble
according to the reversed
assembly sequence.
