5.2.5 Replacing the exhaust light plate
5.2.6 Replacing the brake light plate
1
Remove 5 M4 inner hex
screws and open the cap
of the exhaust pipe.
Exhaust cover
LED light plate holder
LED light plate
2
Remove 2 M4 cruciform
screws and disassemble
the LED light plate.
3
Then take off the LED
light plate and 2 M3
cruciform screws, then
replace the LED light
plate.
4
When done, reassemble
according to the reversed
assembly sequence.
1
Remove 4 M6 inner hex
screws and lift up the
chair.
LED light plate holder
LED light plate
2
Remove 3 M4 cruciform
screws and disassemble
the LED light plate.
3
Then take off the LED
light plate and 8 M3
cruciform screws, and
replace the LED light
plate.
4
When done, reassemble
according to the reversed
assembly sequence.
