IGS WAHLAP TECH OverTake - Host-machine assembly

56
56
5.2.15 Replacing the VR of the pedals of the throttle and brake
5.2.16 Replacing the bass speaker
1
Remove 4 M4 cruciform
screws and take off the
caps in the front and the
back.
VR holder
VR holder
VR
2
Remove 4 M4 cruciform
screws and take off the
VR set.
3
Remove 4 M3 screws
on the VR set and the
electric VR and replace
VR.
4
When done, reassemble
according to the reversed
assembly sequence.
1
Remove 4 cruciform
inner screws and take off
the bass stereo.
Sound box
Bass
2
Remove 3 M4 cruciform
screws and replace the
bass loudspeaker.
3
When done, reassemble
according to the reversed
assembly sequence.
