The length (B) of the ticket is variable, tickets between 90mm and 166mm are
acceptable.
3.7.2.2 Barcode Requirements
The interface the validator is operating in will change the possible value of the
barcode number.
SSP: Barcode length can be between 6 to 24 characters.
ccTalk: Barcode length is fixed to 18 characters, however this is configurable.
Dimension
The barcode itself should be no thinner (E) than 10mm. The narrow bar width
between 0.5mm and 0.6mm, with the wide narrow ratio (W:N) being 2:1.
A blank space (C) is required on either side of the barcode as pictures or text may
be seen as part of the barcode value.
This space should be 10mm.
Positioning
The barcode itself should be centred along the width (D) on the ticket.
