<< Back to Contents
Copyright © Innovative Technology Ltd 2018 Doc: NV9 Range User Manual
Version: 1.0
Page 61 of 63
Only book the credit on the second
Vend pulse!
11.7.1 Escrow Timing Diagram
11.8 Low Power Mode Timing Diagram
