4.3.2 Cashbox Removal
1. Slide Cashbox
Remove the
cashbox from the
outer housing.
Pull cashbox release
catch away from
validator and slide
cashbox out.
Push the tab (1)
seen in the image
whilst sliding the
outer housing back,
so that the locating
tabs are free to
move away from the
validator.
2. Clip-on Cashbox
Simply slide the
cashbox back so
that the locating
tabs are no longer
locked in position.
You can then pull
cashbox away from
unit.
