4 MECHANICAL INSTALLATION
4.1 Compatibility
4.1.1 Hardware Compatibility
4.1.1.1 Machine Mounting
Assuming the suitable bezel (and cashbox) type has been ordered the NV9USB
range can be used as fitting replacement for the following products:
• NV7
• NV7M
• NV9
Please note: Considerations will need to be made when adding either the recycler
or printer module, as this will increase the space requirements inside the host
machine.
The NV11+ and NV12+ have the same space envelope so swapping the recycler for
the printer will not require any mechanical adjustments.
Innovative Technology Ltd. has a policy of continuous product improvement. Due to
design changes, older model or product bezels (and cashboxes) may not be
compatible with the current NV9USB+. However, new product deliveries always
include a bezel (and cashbox) that must be used.
4.1.1.2 Machine Interfacing
By design the NV9USB+ and NV11+ are pin to pin compatible with the fitting
replacement products listed above. No changes to existing machine harnessing are
required.
The NV12+ has an additional connector, in order to power and communicate with
the printer head.
