Intel® 5000 Series Chipsets Server Board Family Datasheet Error Reporting and Handling
Revision 1.1
Intel order number D38960-004
151
Error Code Error Message Response
858C DIMM_D1 Correctable ECC error encountered. Pause
858D DIMM_D2 Correctable ECC error encountered. Pause
858E DIMM_D3 Correctable ECC error encountered. Pause
858F DIMM_D4 Correctable ECC error encountered. Pause
8600 Primary and secondary BIOS IDs do not match. Pause
8601
Override jumper is set to force boot from lower alternate BIOS bank of flash
ROM
Pause
8602 WatchDog timer expired (secondary BIOS may be bad!) Pause
8603 Secondary BIOS checksum fail Pause
5.3.4 POST Error Beep Codes
The following table lists POST error beep codes. Prior to system Video initialization, BIOS uses
these beep codes to inform users on error conditions. The beep code is followed by a user
visible code on the diagnostic LEDs.
Table 51. POST Error Beep Codes
Beeps Error Message POST Progress Code Description
3 Memory error System halted because a fatal error related to the memory
was detected.
6 BIOS rolling back
error
The system has detected a corrupted BIOS in the flash
part, and is rolling back to the last good BIOS.
5.3.5 POST Error Pause Option
For POST error(s) that are listed as Pause, the BIOS enters the error manager and waits for the
user to press an appropriate key before booting the operating system or entering BIOS Setup.
The user can override this option by setting POST Error Pause to disabled in the BIOS Setup
utility Main menu page. If POST Error Pause is set to disabled, the system will boot the
operating system without user-intervention. The default value is set to enabled.
