Intel® 5000 Series Chipsets Server Board Family Datasheet System BIOS
Revision 1.1
Intel order number D38960-004
49
Table 10. POST Memory Error Handling
Scenario POST Message SEL LED State IPMI MEM States
Updated
System Operation
POST Memory BIST
Uncorrectable Error
(UE) (hard error)
Uncorrectable error
message that
identifies FBDIMM
location
UE POST code
DIMM failed POST code
SEL messages identify
FBDIMM location
DIMM LED: Lit for the
failed FBDIMM only.
System fault LED: Not
lit.
DIMM fail status = Y
Disabled status = Y
The system continues to boot if
good memory is found. If only bad
memory is found, the system
emits a beep code and displays a
POST diagnostic LED message.
POST Memory FB-
DIMM Intel
®
IBIST
Error
Uncorrectable error
message that identify
FBDIMM location(s)
UE POST code
DIMM failed POST code
SEL messages identify
FBDIMM location(s)
DIMM LED: Lit for all
affected FBDIMMs.
System fault LED: Not
lit.
Fail status = Y
Disabled status = Y
The system will disable all
FBDIMMs on the FBDIMM
channel that failed. The system
will continue to function normally
if there are good FBDIMMs to be
found on the other channel or
branch. The system will light fault
LEDs for all FBDIMMs, starting
from the first, that failed IBIST
irrespecctive of whether these
DIMM sockets are populated or
not. This is to indicative a
broader-level channel or branch
failure.
