System BIOS Intel® 5000 Series Chipsets Server Board Family Datasheet
Revision 1.1
Intel order number D38960-004
74
Table 21. Setup Utility — Serial Ports Configuration Screen Fields
Setup Item Option Help Text Comment
COM1
Enable
Enabled
Disabled
Enables or disables COM1 port.
Address
3F8h
2F8h
3E8h
2E8h
Selects the base I/O address for COM1.
IRQ 3
4
Selects the Interrupt Request line for COM1.
COM2
Enable
Enabled
Disabled
Enables or disables COM1 port.
Address 3F8h
2F8h
3E8h
2E8h
Selects the base I/O address for COM1.
IRQ
3
4
Selects the Interrupt Request line for COM1.
3.7.2.1.6 USB Configuration Screen
The USB Configuration screen provides fields to configure the USB controller options.
To access this screen from the Main screen, select Advanced | USB Configuration.
Figure 14. Setup Utility — USB Controller Configuration Screen Display
