System BIOS Intel® 5000 Series Chipsets Server Board Family Datasheet
Revision 1.1
Intel order number D38960-004
48
3.3.10.3 Mirroring Mode Errors
When mirroring mode is enabled, the BIOS will report errors in accordance with the following
table:
Table 9. Mirroring Mode Errors
Event Actions
Mirroring mode selected by the user, but the BIOS failed
to configure the system in mirroring mode.
Error message in the error manager at end of POST.
Error ID 0x85FD
Current Memory Configuration field in the Advanced |
Memory tab in the BIOS Setup utility indicates maximum
performance or single-channel mode, depending upon
the FBDIMM population
Correctable error in the primary or secondary branch.
Number of errors is less than the threshold of 10
SEL generated with Sensor Offset = Correctable Error.
Correctable error in primary or seconday branch, number
of such errors in the same branch reaches the threshold
of 10.
SEL generated with Sensor Offset = Correctable Error
SEL generated with Sensor Offset = Correctable Error
Threshold
DIMM fault LED for the failed DIMM lights.
First uncorrectable ECC error in primary and secondary
branch
SEL generated with Sensor Offset = Uncorrectable Error.
Failed memory is taken off-line.
DIMM fault LED for the failed FBDIMM is lit.
NMI is asserted.
Note: Memory sparing and mirroring features are currently disabled and will be made available
after production launch.
