Intel® 5000 Series Chipsets Server Board Family Datasheet System BIOS
Revision 1.1
Intel order number D38960-004
71
Setup Item Option Help Text Comment
AHCI Mode Enable
Disable
Help: AHCI Mode Unavailable if the SATA mode is
“Legacy” or if RAID Mode is
selected.
If AHCI is enabled, no information
for HDD will be displayed
because the BIOS does not
identify any drives when AHCI is
enabled.
The identification and
configuration is left to the AHCI
Option ROM. A user will not see
any HDD information in BIOS
Setup.
Configure SATA as
RAID
Enable
Disable
Help: Configure Intel
®
Embedded RAID
Technology II
Unavailable when AHCI mode is
enabled. This mode can be
selected only when the SATA
contoller is in Enhanced Mode.
Staggard Spin Up
Support
Enable
Disable
Help: Staggard Spin Up
Support
Available only when AHCI Mode
is enabled
Primary IDE Master Disabled / Drive information Information only
Primary IDE Slave Disabled / Drive information Information only
SATA 0 Disabled / Drive information Information only; Unavailable
when AHCI or RAID Mode is
enabled
SATA 1 Disabled / Drive information Information only; This field is
unavailable when AHCI or RAID
Mode is enabled
SATA 2 Disabled / Drive information Information only; This field is
unavailable when AHCI or RAID
Mode is enabled
SATA 3 Disabled / Drive information Information only; This field is
unavailable when AHCI or RAID
Mode is enabled
SATA 4 Disabled / Drive information Information only; This field is
unavailable when AHCI or RAID
Mode is enabled
SATA 5 Disabled / Drive information Information only; This field is
unavailable when AHCI or RAID
Mode is enabled
