Figure 69. RSU Image Layout - Your Perspective
In this figure:
• SPT0 and SPT1 point to everything:
— BOOT_INFO
— Factory Image
— Pointer Block 0 and Pointer Block 1
— All Application Images
• Pointer Block 0 and Pointer Block 1 point to all Application Images
BOOT_INFO
Factory Image
Sub Partition Table 0
Sub Partition Table 1
Pointer Block 0
Pointer Block 1
Application Image 0
Application Image 1
Higher Addresses
base
Can only be updated through an update image
Can be written directly
SDM does not use
To summarize, your view of flash memory is different from SDM view in two ways:
