SDM Pins MSEL Function Configuration Source Function

Avalon-ST x8 AS x4

SDM_IO2

—

AVSTx8_DATA0 AS_CLK

SDM_IO3

—

AVSTx8_DATA3 AS_DATA2

SDM_IO4

—

AVSTx8_DATA1 AS_DATA0

SDM_IO5 MSEL0

—

AS_nCSOO

SDM_IO6

—

AVSTx8_DATA4 AS_DATA3

SDM_IO7 MSEL1

—

AS_nCSO2

SDM_IO8

—

AVSTx8_READY AS_nCSO3

SDM_IO9 MSEL2

—

AS_nCSO1

SDM_IO10

—

AVSTx8_DATA7

—

SDM_IO11

—

AVSTx8_VALID

—

SDM_IO12

— — —

SDM_IO13

—

AVSTx8_DATA5

—

SDM_IO14

—

AVSTx8_CLK

—

SDM_IO15

—

AVSTx8_DATA6 AS_nRST

SDM_IO16

— — —

2.5.2. MSEL Settings

After power-on MSEL[2:0] pins specify the configuration scheme for Intel Agilex devices. Use 4.7-kΩ resistors to pull the

MSEL[2:0] pins up to V

CCIO_SDM

or down to ground as required by the MSEL[2:0] setting for your configuration scheme.

2. Intel Agilex Configuration Details

683673 | 2021.10.29
