Figure 71. Specifying Parameters for an Application .rpd Stored in Flash Memory
Specify Configuration Mode
Select Raw Programming Data
Specify Output Directory
Specify Output File Name
Specify Device Family
Select Relative Address
Edit
Specify Start Address in Flash
7.
By default, the .rpd file type is little-endian, if you are using a third-party programmer that does not support the little-
endian format. Set the Bit swap to On to generate the .rpd file in big endian format.
Note: The rsu1.tcl script that Intel provides performs the bit swap operation. Consequently, if you are using this script, set
Bit swap to Off.
8.
On the Input Files tab, click Add Bitstream. Change the Files of type to SRAM Object File (*.sof). Then, select
application image .sof file and click Open.
5. Remote System Update (RSU)
683673 | 2021.10.29
Intel
®
Agilex
™
Configuration User Guide
Send Feedback
188
