Intel Desktop Board D815EEA2/D815EPEA2 Technical Product Specification
14
1.2 Overview
1.2.1 Feature Summary
Table 2 summarizes the D815EEA2 and D815EPEA2 boards’ major features.
Table 2. Feature Summary
Form Factor
ATX (11.55 inches by 8.20 inches)
Processor Support for either an Intel
®
Pentium
®
III processor in a Flip Chip Pin Grid Array
(FC-PGA) package or an Intel
®
Celeron
™
processor in an FC-PGA package
Memory • Three 168-pin SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for up to 512 MB system memory
• Support for single-sided or double-sided DIMMs
Chipsets
• The D815EEA2 board includes the Intel 815E Chipset, consisting of:
Intel
82815 Graphics and Memory Controller Hub (GMCH)
Intel
®
82801BA I/O Controller Hub (ICH2)
SST 49LF004A 4 Mbit Firmware Hub (FWH)
• The D815EPEA2 board includes the Intel 815EP Chipset, consisting of:
Intel 82815EP Memory Controller Hub (MCH)
Intel 82801BA I/O Controller Hub (ICH2)
SST 49LF004A 4 Mbit Firmware Hub (FWH)
I/O Control SMSC LPC47M132 LPC bus I/O controller
Video • The D815EEA2 board includes:
Intel
82815 integrated graphics support
AGP universal connector supporting 1x, 2x, and 4x AGP cards or a
Graphics Performance Accelerator (GPA)
• The D815EPEA2 board includes an AGP universal connector supporting
1x, 2x, and 4x AGP cards
Audio
• Intel 82801BA ICH2 digital controller (AC link output)
• Analog Devices AD1885 Audio Codec
Peripheral
Interfaces
• Four Universal Serial Bus (USB) ports
• Two serial ports
• One parallel port
• Two IDE interfaces with Ultra DMA, ATA-66/100 support
• One diskette drive interface
• PS/2
†
keyboard and mouse ports
Expansion
Capabilities
• Five PCI bus add-in card connectors (SMBus routed to PCI bus connector 2)
• One AGP universal connector
BIOS • Intel/AMI BIOS (stored in an SST 49LF004A 4 Mbit FWH)
• Support for Advanced Power Management (APM), Advanced Configuration and
Power Interface (ACPI), Plug and Play, and SMBIOS
continued
