Product Description
17
1.2.4 Block Diagrams
Figure 3 is a block diagram of the major functional areas of the D815EEA2 board.
Optional
815E Chipset
82801BA
I/O Controller Hub
(ICH2)
82815
Graphics and
Memory Controller
Hub (GMCH)
SST 49LF004A
Firmware Hub
(FWH)
AHA
Bus
System BusProcessor Socket
DIMM
Banks
(3)
Primary/
Secondary IDE
Diskette Drive
Connector
LPC I/O
Controller
PS/2 Keyboard
PS/2 Mouse
Parallel Port
Serial Port A
Serial Port B
AGP
Universal
Connector
ATA-66/100
USB
AC Link
AGP Bus
LPC
Bus
OM11889
SDRAM Bus
USB Ports 0 and 1
USB Ports 2 and 3
DVO
Connector
(Optional)
Digital Video
Output
Auxiliary Line In
Mic In
Line Out
CD-ROM
Line In
Front Panel
Audio (optional)
CNR
Connector
LAN
Connector
Physical
Layer
Interface
PCI Slot 1
PCI Slot 2
PCI Slot 3
PCI Slot 4
PCI Slot 5
Network
Analog
Codec
Onboard
Video
Video
Bus
indicates connector or socket
Hardware
Monitor
SMBus
PCI Bus
Figure 3. Block Diagram for the D815EEA2 Board
