2.8 Connectors
CAUTION
Only the back panel connectors of the D815EEA2 and D815EPEA2 boards have overcurrent
protection. The D815EEA2 and D815EPEA2 boards’ internal connectors are not overcurrent
protected and should connect only to devices inside the computer’s chassis, such as fans and
internal peripherals. Do not use these connectors to power devices external to the computer’s
chassis. A fault in the load presented by an external device may result in a high output current that
could damage the board, the interconnecting cable, and the external device itself.
For information about Refer to
Overcurrent protection for the board’s back panel connectors Table 19, page 65
This section describes the board’s connectors. The connectors can be divided into the following
groups:
• Back panel I/O connectors (see page 64)
PS/2 keyboard and mouse
USB (four)
VGA (present only on D815EEA2 boards)
Parallel port
Serial port A
LAN (optional)
Audio (line in, line out, and mic in)
• Internal I/O connectors (see page 68)
Audio (auxiliary line input, ATAPI CD-ROM, and optional front panel audio)
Digital video output (optional; present only on D815EEA2 boards)
Fans
Power
Chassis intrusion (optional)
Wake on LAN technology (optional)
Add-in boards (one optional CNR connector, one AGP universal connector, and five PCI
bus connectors)
IDE (two)
Diskette drive
• External I/O connectors (see page 78)
SCSI LED
Serial port B
Front panel USB (optional)
Front panel (power/sleep/message waiting LED, power switch, hard drive activity LED,
reset switch, and auxiliary front panel LED)
