Product Description
15
Table 2. Feature Summary (continued)
Instantly Available
PC
• Support for PCI Local Bus Specification Revision 2.2
• Suspend to RAM support
• Wake on PS/2 keyboard and USB ports
Hardware Monitor
Subsystem
• Voltage sense to detect out of range values
• Two fan sense inputs used to monitor fan activity
SCSI LED
Connector
Allows add-in SCSI host bus adapters to use the same LED as the onboard I/O
controller
For information about Refer to
The board’s compliance level with APM, ACPI, Plug and Play, and SMBIOS Table 4, page 20
1.2.2 Manufacturing Options
Table 3 describes the D815EEA2 and D815EPEA2 boards’ manufacturing options. Not every
manufacturing option is available in all marketing channels. Please contact your Intel
representative to determine which manufacturing options are available to you.
Table 3. Manufacturing Options
Chassis fan connector Connector for an additional chassis fan
Chassis Intrusion
Connector
Detects chassis intrusion
Communication and
Networking Riser (CNR)
Connector
One CNR connector (slot shared with PCI bus connector 3)
Diagnostic LEDs Four dual-color LEDs on the back panel
Front Panel Audio
Connector
Routes mic in and line out to the front panel
Front Panel USB
Connector
Provides access to two additional USB ports, routed through the optional
SMSC LPC47M142 I/O controller
I/O Control SMSC LPC47M142 LPC bus I/O controller
LAN Subsystem Intel
®
82562ET 10/100 Mbit/sec Platform LAN Connect (PLC) device
Video Digital Video Output (DVO) connector
Wake on LAN
†
Technology Connector
Support for system wake up using an add-in network interface card with
remote wake up capability
