1.12 LAN Subsystem (Optional)
The network interface controller subsystem consists of the ICH2, with integrated LAN Media
Access Controller (MAC), and a physical layer interface device. Features of the LAN subsystem
include:
• PCI Bus Master Interface
• CSMA/CD Protocol Engine
• Serial CSMA/CD unit interface that supports the following physical layer interface devices:
82562ET onboard LAN
82562ET/MT (10/100 Mbit/sec Ethernet) on the optional CNR
82562EH (1 Mbit/sec HomePNA
†
) on the optional CNR
• PCI Power Management
Supports APM
Supports ACPI technology
Supports Wake up from suspend state (optional Wake on LAN technology)
For information about Refer to
Obtaining LAN software and drivers Section 1.3, page 19
1.12.1 Intel
®
82562ET Platform LAN Connect Device
The Intel 82562ET component provides an interface to the back panel RJ-45 connector with
integrated LEDs. This physical interface may alternately be provided through the CNR connector.
The Intel 82562ET provides the following functions:
• Basic 10/100 Ethernet LAN Connectivity
• Supports RJ-45 connector with status indicator LEDs
• Full driver compatibility
• Advanced Power Management support
• Programmable transit threshold
• Configuration EEPROM that contains the MAC address
1.12.2 RJ-45 LAN Connector LEDs
Two LEDs are built into the RJ-45 LAN connector. Table 8 describes the LED states when the
board is powered up and the LAN subsystem is operating.
Table 8. LAN Connector LED States
LED Color LED State Condition
Off 10 Mbit/sec data rate is selected. Green
On 100 Mbit/sec date rate is selected.
Off LAN link is not established.
On (steady state) LAN link is established.
Yellow
On (brighter and pulsing) The computer is communicating with another computer on
the LAN.
