1.15.1.2.2 Wake Up Devices and Events
Table 11 lists the devices or specific events that can wake the computer from specific states.
Table 11. Wake Up Devices and Events
These devices/events can wake up the computer… …from this state
Power switch S1, S3, S5
RTC alarm S1, S3, S5
(Note 1)
Wake on LAN technology connector (optional) S1, S3, S5
(Notes 1 and 2)
PME# S1, S3, S5
(Notes 1 and 2)
Modem (back panel serial port A) S1, S3
(Note 3)
USB S1, S3
PS/2 keyboard S1, S3
Notes:
1. S5 events are supported only on PCI bus connector 2.
2. For the Wake on LAN technology connector and PME#, S5 is disabled by default in the BIOS Setup program. Setting
these options to Power On will enable a wake-up event from LAN in the S5 state.
3. Wake from CNR modem is not supported on the D815EEA2 and D815EPEA2 boards.
✏
NOTE
The use of these wake up events from an ACPI state requires an operating system that provides full
ACPI support. In addition, software, drivers, and peripherals must fully support ACPI wake
events.
✏
NOTE
Wake up from PS/2 mouse is peripheral, operating system, and driver dependent; it is not a board-
level feature.
1.15.1.2.3 Plug and Play
In addition to power management, ACPI provides controls and information so that the operating
system can facilitate Plug and Play device enumeration and configuration. ACPI is used only to
enumerate and configure D815EEA2 and D815EPEA2 board devices that do not have other
hardware standards for enumeration and configuration. PCI devices on the D815EEA2 and
D815EPEA2 boards, for example, are not enumerated by ACPI.
