Intel D815EEA2 User Manual

Technical Reference
85
2.10.2 I/O Shields
The back panel I/O shields for the D815EEA2 and D815EPEA2 boards must meet specific
dimension and material requirements. Systems based on this board need the back panel I/O shield
to pass emissions (EMI) certification testing. Figure 19, Figure 20, and Figure 21 show the critical
dimensions of the chassis-dependent I/O shield for the Universal boards. Figure 22, Figure 23, and
Figure 24 show the critical dimensions of the chassis-dependent I/O shield for earlier versions of
the boards. Dimensions are given in inches [millimeters], to a tolerance of ± 0.020 inches [0.508
millimeters].
These figures also indicate the position of each cutout. Additional design considerations for I/O
shields relative to chassis requirements are described in the ATX specification.
For information about Refer to
The ATX specification Table 4, page 19
✏
NOTE
An I/O shield compliant with the ATX chassis specification 2.03 is available from Intel.
