Technical Reference
93
Table 53 lists the power usage for a D815EEA2 board with the configuration listed on the previous
page and including the optional onboard LAN subsystem.
Table 53. Power Usage for a D815EEA2 Board with Onboard LAN
DC Current at:
Mode AC Power +3.3 V +5 V +12 V -12 V +5 V (standby)
Windows 98 SE APM full on 54 W 2.02 A 3.22 A 0.18 A 0.00 A 0.26 A
Windows 98 SE APM standby 29 W 1.58 A 0.50 A 0.18 A 0.00 A 0.04 A
Windows 98 SE ACPI S0 33 W 1.68 A 0.26 A 0.18 A 0.00 A 0.26 A
Windows 98 SE ACPI S1 28 W 1.58 A 0.48 A 0.18 A 0.00 A 0.18 A
Windows 98 SE ACPI S3 1 W 0.00 A 0.00 A 0.00 A 0.00 A 0.22 A
Table 54 lists the power usage for a D815EPEA2 board with the configuration listed on the
previous page, but without the optional onboard LAN subsystem and with an add-in 2x 4 MB AGP
graphics card.
Table 54. Power Usage for a D815EPEA2 Board with Add-in Graphics Card, without
Onboard LAN
DC Current at:
Mode AC Power +3.3 V +5 V +12 V -12 V +5 V (standby)
Windows 98 SE APM full on 55 W 2.45 A 3.40 A 0.20 A 0.00 A 0.12 A
Windows 98 SE APM standby 34 W 2.28 A 0.50 A 0.20 A 0.00 A 0.09 A
Windows 98 SE ACPI S0 35 W 2.42 A 0.51 A 0.20 A 0.00 A 0.11 A
Windows 98 SE ACPI S1 29 W 2.28 A 0.49 A 0.20 A 0.00 A 0.09 A
Windows 98 SE ACPI S3 1 W 0.00 A 0.00 A 0.00 A 0.00 A 0.12 A
