Intel D815EEA2 User Manual

Product Description
23
1.6 Processor
CAUTION
Use only the processors listed below. Use of unsupported processors can damage the board, the
processor, and the power supply. See the Intel Desktop D815EEA2/D815EPEA2 Specification
Update for the most up-to-date list of supported processors for the D815EEA2 and D815EPEA2
boards.
The D815EEA2 and D815EPEA2 boards both support a single Pentium III or Celeron processor.
The system bus frequency is automatically selected. The D815EEA2 and D815EPEA2 boards
support the processors listed in Table 5.
Table 5. Supported Processors
Type Designation System Bus Frequency L2 Cache Size
533EB, 600EB, 667, 733,
800B, 866, and 933 MHz
1.0 GHz
133 MHz 256 KB Pentium III processor in
an FC-PGA package
500E, 550E, 600E, 650, 700,
750, 800, and 850 MHz
100 MHz 256 KB
800 and 850 MHz 100 MHz 128 KB Celeron processor in an
FC-PGA package
533A, 566, 600, 633, 667, 700,
733, and 766 MHz
66 MHz 128 KB
All supported onboard memory can be cached, up to the cachability limit of the processor. See the
processor’s data sheet for cachability limits.
For information about Refer to
Product information on supported processors Section 1.3, page 19
Processor data sheets Section 1.3, page 19
