Intel Desktop Board D815EEA2/D815EPEA2 Technical Product Specification
50
1.15.1.2.1 System States and Power States
Under ACPI, the operating system directs all system and device power state transitions. The
operating system puts devices in and out of low-power states based on user preferences and
knowledge of how devices are being used by applications. Devices that are not being used can be
turned off. The operating system uses information from applications and user settings to put the
system as a whole into a low-power state.
Table 10 lists the power states supported by the D815EEA2 and D815EPEA2 boards along with the
associated system power targets. See the ACPI specification for a complete description of the
various system and power states.
Table 10. Power States and Targeted System Power
Global States Sleeping States CPU States Device States
Targeted System Power
(Note 1)
G0 – working
state
S0 – working C0 – working D0 – working state Full power > 30 W
G1 – sleeping
state
S1 – CPU stopped C1 – stop grant D1, D2, D3 –
device
specification
specific.
5 W < power < 30 W
G1 – sleeping
state
S3 – suspend to
RAM. Context
saved to RAM.
No power D3 – no power
except for wake
up logic.
Power < 5 W
(Note 2)
G2/S5 S5 – soft-off.
Context not
saved. Cold boot
is required.
No power D3 – no power
except for wake
up logic.
Power < 5 W
(Note 2)
G3 –
mechanical off
AC power is
disconnected
from the
computer.
No power to the
system.
No power D3 – no power for
wake up logic,
except when
provided by
battery or external
source.
No power to the system so
that service can be
performed.
Notes:
1. Total system power is dependent on the system configuration, including add-in boards and peripherals
powered by the system chassis’ power supply.
2. Dependent on the standby power consumption of wake-up devices used in the system.
