Intel D815EEA2

Intel Desktop Board D815EEA2/D815EPEA2 Technical Product Specification
90
Pictorial
View
OM11485
0.063 0.005
[1.600 0.120]
8X R0.5 MIN
A
REF 6.390
[162.300]
0.787 0.010 TYP [20 0.254]
3x Dia 0.039 [1.000]
0.884
[22.450]
0.276
[7.012]
0.465
[11.811]
0.567
[14.400]
0.000
[0.000]
0.000 [0.000]
0.447
[11.345]
1.195
[30.360]
2.081
[52.854]
3.219
[81.768]
4.840
[122.950]
5.771
[146.577]
0.567
[14.400]
0.472
[12.000]
0.465
[11.810]
0.027
[0.690]
0.519
[13.190]
3x Dia 0.330 [8.380]
Figure 23. I/O Shield Dimensions
(for D815EPEA2 Boards with Onboard LAN Subsystem)
