5.6 Diagnostic LEDs (Optional)
The optional enhanced diagnostics feature consists of a hardware decoder and four LEDs located
between the LAN connector and the parallel port connector on the back panel. This feature
requires no modifications to the chassis (other than I/O back panel shield) or cabling.
Figure 26 shows the location of the diagnostic LEDs. Table 93 lists the diagnostic codes displayed
by the LEDs.
OM11462A
1
4
Present only on D815EEA2 boards
Figure 26. Diagnostic LEDs
