Intel Desktop Board D815EEA2/D815EPEA2 Technical Product Specification
44
• Back panel audio connectors:
 Line in
 Line out
 Mic in
For information about Refer to
The back panel audio connectors Section 2.8.1, page 64
1.11.2.1 Front Panel Audio Connector (Optional)
A 2 x 5-pin connector for routing mic in and line out to the front panel.
For information about Refer to
The location of the optional front panel audio connector Figure 14, page 69
The signal names of the optional front panel audio connector Table 30, page 70
✏
NOTE
The front panel audio connector is alternately used as a jumper block for routing audio signals.
Refer to Section 2.9.1 on page 82 for more information.
1.11.2.2 ATAPI CD-ROM Connector
A 1 x 4-pin ATAPI-style connector connects an internal ATAPI CD-ROM drive to the audio mixer.
For information about Refer to
The location of the ATAPI CD-ROM connector Figure 14, page 69
The signal names of the ATAPI CD-ROM connector Table 31, page 70
1.11.2.3 Auxiliary Line In Connector
A 1 x 4-pin ATAPI-style connector connects the left and right channel signals of an internal audio
device to the audio subsystem.
For information about Refer to
The location of the auxiliary line in connector Figure 14, page 69
The signal names of the auxiliary line in connector Table 29, page 70
