Intel D815EEA2

Product Description
41
1.10.1.3 AGP Universal Connector
✏
NOTE
Install memory in the DIMM sockets prior to installing the AGP video card to avoid interference
with the memory retention mechanism.
The AGP universal connector supports either:
• Graphics Performance Accelerator (GPA) cards with 133 MHz SDRAM display cache
• 1x, 2x, or 4x AGP add-in cards with either 3.3 V or 1.5 V I/O
For information about Refer to
The location of the AGP universal connector Figure 15, page 73
The signal names of the AGP universal connector Table 41, page 76
1.10.1.3.1 Graphics Performance Accelerator (GPA) Support
The Intel 815E GMCH display cache is a single channel 32-bit wide SDRAM interface. The
4 MB display cache resides on a GPA card that plugs into the AGP connector. The BIOS detects a
GPA card if present in the AGP port and initializes it as display cache memory. When a GPA card
is initialized, the BIOS allocates 1 MB of system memory to support the internal display device
operation.
1.10.1.3.2 Dynamic Video Memory Technology (DVMT)
DVMT enables enhanced graphics and memory performance through Direct AGP, and highly
efficient memory utilization. DVMT ensures the most efficient use of all available memory for
maximum 2D/3D graphic performance. DVMT is implemented on the D815EEA2 board with a
GPA (Graphics Performance Accelerator) card installed in the AGP connector.
✏ NOTE
In earlier documentation, the GPA card was referred to as the AGP Inline Memory Module
(AIMM).
DVMT uses 1 MB of system physical memory for compatibility with legacy applications. An
example of this would be when using VGA graphics under DOS. Once loaded, the operating
system and graphics drivers allocate the buffers needed for performing graphics functions. When
the 4 MB GPA card is installed, the Z-buffer and GDI data are managed directly from this
dedicated graphics memory thereby avoiding operating system memory manager calls and
improving performance.
At system BIOS POST, the BIOS displays either the amount of physical memory allocated for
display cache or the size of the GPA card (4 MB) if installed. Operating systems such as
Windows NT 4.0 and Windows 2000 may display the maximum amount of frame buffer memory
possible based on the system memory configuration.
