Intel® Server Board S2600IP and Intel® Workstation Board W2600CR TPS Appendix B: BMC Sensor
Tables
Revision 1.1
Intel order number G34153-003
131
Full Sensor
Name
(Sensor name
in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/Reading
Type
Event Offset
Triggers
Contrib.
To
System
Status
Assert/De-
assert
Readable
Value/
Offsets
Event
Data
Rearm
Stand-
by
PCI Riser 2
Temperature
(PCI Riser 2
Temp)
2Ch
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-
fatal
As and De
Analog
R, T
A
X
SAS Module
Temperature
(SAS Mod
Temp)
2Dh
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-
fatal
As and De
Analog
R, T
A
X
Exit Air
Temperature
(Exit Air Temp)
2Eh
Chassis and
Platform
Specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-
fatal
As and De
Analog
R, T
A
X
Network
Interface
Controller
Temperature
(LAN NIC
Temp)
2Fh
All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-
fatal
As and De
Analog
R, T
A
X
Fan
Tachometer
Sensors
(Chassis
specific
sensor names)
30h–
3Fh
Chassis and
Platform
Specific
Fan
04h
Threshold
01h
[l] [c,nc]
nc =
Degraded
c = Non-
fatal
2
As and De
Analog
R, T
M
-
Fan Present
Sensors
(Fan x Present)
40h–
4Fh
Chassis and
Platform
Specific
Fan
04h
Generic
08h
01 - Device
inserted
OK
As and De
-
Triggered
Offset
Auto
-
Power Supply 1
Status
(PS1 Status)
50h
Chassis-
specific
Power Supply
08h
Sensor
Specific
6Fh
00 - Presence
OK
As and De
–
Trig
Offset
A
X
01 - Failure
Degraded
02 – Predictive
Failure
Degraded
03 - A/C lost
Degraded
