Intel Xeon Phi Processor x200 User Manual

Order Number: 334785-002 Intel
®
Xeon
®
Phi™ Processor x200 Product Family TMSDG
35

Retention Assembly Mechanical Design
.
Figure 4-3. Processor Package Carrier
Pin A1
Alignment
Mark
Package
Alignment
Feature
Package
Clip
Heatsink
Alignment
And Attach
Clips
Figure 4-4. Processor with Fabric Package Carrier
Pin A1
Alignment
Mark
Package
Alignment
Feature
Package
Fabric End
Alignment Clip
Heatsink
Alignment
And Attach
Clips
The keying features on the carrier ensure the processor package snaps into the carrier
in only one way, and the carrier itself can be attached to the heatsink in only one
orientation.
