Figure E-12. Backplate Insulator
13
4
5678
B
C
D
A
123
4
5678
B
C
D
A
2200 MISSION COLLEGE BLVD.
P.O. BOX 58119
SANTA CLARA, CA 95052-8119
R
B
0.1 A
0.24 A B
44
2X 32
2X 26
2X 44
2X 70
THICK
WITH ADHESIVE APPLIED 3
0.18
+0.05
-0.02
13
35 35
82.1
109.1
7X 4.5 0.25
A
G93724 1 07
DWG. NO SHT. REV
SHEET 1 OF 1
DO NOT SCALE DRAWING
SCALE: 2:1
07G93724D
REV
DRAWING NUMBER
SIZE
KNL BACKPLATE INSULATOR
TITLE
DEPARTMENT
SEE NOTESSEE NOTES
FINISHMATERIAL
-
DATEAPPROVED BY
9/3/15
DATECHECKED BY
08/14/13
DATEDRAWN BY
08/14/13
DATEDESIGNED BY
DIMENSIONS ARE IN MILLIMETERS
THIRD ANGLE PROJECTION
REVISION HISTORY
ZONE REV DESCRIPTION DATE APPR
- 01 TOOLING RELEASE 8/20/14
02
CHANGED OUTER PERIMETER, CENTER, AND FOUR SQUARE OPENING
DIMENSIONS. NEW PART NUMBER -002.
9/12/14
03
UPDATED DRAWING FOR COMPLIANCE WITH GD&T STANDARD,
SPECIFIED ADHESIVE
3/26/15
04
1. ADDED NOTE 4 TO CALL OUT CRITICAL TO FUNCTION DIMENSIONS
2. UPDATED PROFILE TOLERANCE.
5/7/15
PG1 B2
PG1 C4
05
1. REMOVED CTF CALLOUT SYMBOL TO OUTER BASIC DIMENSIONS.
2. INCREASED DIAMETER TOLERANCE FROM .12 TO .25.
5/21/15
06
1. REMOVED DIMENSIONS.
2. INCREASED PROFILE TOLERANCE IN NOTE 2 FROM 0.2 TO 0.24
9/8/15
PG1 C4 07
1. REMOVED CTF DIMENSION.
7/11/16
NOTES; UNLESS OTHERWISE SPECIFIED:
1. REFERENCE DOCUMENTS
ASME Y14.5M-2009 - STANDARD DIMENSION AND TOLERANCES
2. FEATURES NOT SPECIFIED ON DRAWING AND FEATURES WITHOUT SPECIFIED
TOLERANCE SHALL BE CONTROLLED BY 3D CAD DATABASE
3 MATERIAL: MAY USE INTEL ENGINEERING APPROVED EQUIVALENTS.
CRITICAL MECHANICAL PROPERTIES:
A) HALOGEN FREE POLYCARBONATE SHEET PC-1860B (CHENGDU
KANGLONGXIN PLASTICS CO,.LTD.)
0.127MM NOMINAL THICKNESS, ONE SIDE ADHESIVE (NIKTO 8905)
APPLIED; TOTAL THICKNESS= 0.18MM.
B) FLAMMABILITY: UL 94-V0 OR VTM-0 RATING.
4. DIMENSIONS MARKED ARE CRITICAL TO FUNCTION DIMENSIONS (CTF).
TOP SIDE
BOTTOM SIDE (ADHESIVE SIDE)
C
PARTS LIST
DESCRIPTIONPART NUMBER
ITEM NO
QTY
KNL BACKPLATE INSULATORG93724-002TOP
