Figure E-19. Bolster Plate, LEC Guide Pin
A A
13
4
5678
B
C
D
A
123
4
5678
B
C
D
A
B
2200 MISSION COLLEGE BLVD.
P.O. BOX 58119
SANTA CLARA, CA 95052-8119
R
0.2 A B
R0.2 0.1
2.5 0.03
2.66 0.03
2.9±0.05
A
H78231 1 06
DWG. NO SHT. REV
SHEET 1 OF 1
DO NOT SCALE DRAWING
SCALE: 50:1
06H78231D
REV
DRAWING NUMBER
SIZE
KNL BOLSTER LEC GUIDE PIN
TITLE
DEPARTMENT
SEE NOTESSEE NOTES
FINISHMATERIAL
DATEAPPROVED BY
-
9/11/15
DATECHECKED BY
3/25/15
DATEDRAWN BY
3/25/15
DATEDESIGNED BY
DIMENSIONS ARE IN MILLIMETERS.
THIRD ANGLE PROJECTION
PARTS LIST
DESCRIPTIONPART NUMBER
ITEM NO
QTY
KNL BOLSTER LEC GUIDE PINH78231-004TOP
REVISION HISTORY
ZONE REV DESCRIPTION DATE APPR
- 01 TOOLING RELEASE 3/25/15
B6 02 ADDED STEP IN SHAFT, CHANGED DIAMETER, PART NUMBER TO -002 4/6/15
A7 03 ADDED RECESS IN HEAD FOR ASSEMBLY, PART NUMBER TO -003 4/16/15
04
UPDATED NOTE 4 SYMBOL CALL-OUT FOR CRITICAL
TO FUNCTION DIMENSIONS.
4/23/15
6-A
05
1. REMOVED THE PIN HEAD
2. ROLLED THE DASH PART NUMBER FROM H78231-003 TO H78231-004
8/28/15
A5 06 1. REMOVED CTF DIMENSION. 7/11/16
NOTES; UNLESS OTHERWISE SPECIFIED
1. REFERENCE DOCUMENTS
ASME Y14.5M-2009 - DIMENSIONING AND TOLERANCING
2. FEATURES NOT SPECIFIED ON DRAWING SHALL BE
CONTROLLED BY 3D CAD DATABASE
FOR FEATURES NOT EXPLICITLY TOLERANCED:
(BASIC DIMENSIONS FROM THE 3D CAD MODEL).
3. CRITICAL MATERIAL PROPERTIES:
- MATERIAL: 18-8 STAINLESS STEEL; AISI 303, 304, 305;
JIS SUS304 OR EQUIVALENT
- PROCESS TEST: 168 HRS 85
C / 85% HUMIDITY WITH NO
VISIBLE CORROSION
4.DIMENSIONS MARKED WITH CRITICAL TO FUNCTION
DIMENSIONS (CTF).
5. SHARP CORNERS MUST BE CHAMFERED OR ROUNDED TO 0.25MM
RADIUS MAX. EDGES AROUND PERIMETER OF PART ARE
SUBJECT TO HANDLING AND ARE REQUIRED TO MEET UL1439 TEST.
SECTION A-A
C
C
