Planning Installation
15
4.3.3 Packing List
Before beginning installation, make sure you have all the included components.
The User Terminal (UT) is composed of the following components.
OW70L-Dac (without Heating Module)
Primary Antenna Package (Box 1)
Item Q'ty Size Description
Primary Antenna Unit 1 Primary User Terminal
Quick Installation Guide (QIG) 1 Installation Manual
Customer Network Exchange (CNX) 1
114.2 mm x 125 mm
x 35.2 mm
To access to OneWeb services
Power Adapter (AC-DC) For CNX 1
To convert 100-240 V AC power to +56 V DC for
CNX (250 W)
AC Power Cord (USA) 1 1.5 m AC Power Cord (110 V)
AC Power Cord (CEEE7/7) 1 1.5 m AC Power Cord (220 V)
Coax Cable (RG 6) 1 30 m F-type, For CNX power & data connection
Hex Bolt 8 M12 x 40L
Spare Bolt Kit for Mast AssemblyFlat Washer 8 M12
Spring Washer 8 M12
Hex-S Bolt SF STS316L 2 M5x8 Spare Grounding screw
RF Hazard Sticker 1 Radiation Safety Distance (13 m) Label
Secondary Antenna Package (Box 2)
Item Q'ty Size Description
Secondary Antenna Unit 1 Secondary User Terminal
Hex-S Bolt SF STS316L 2 M5 x 8 Spare Grounding screw
RF Cable (LMR400) 2 5 m For inter-dome RF Rx & Tx connection
Ethernet Cable (CAT 5) 1 5 m For inter-dome Ethernet connection
Signal Cable (CAT 5) 1 5 m For inter-dome control signal connection
RF Hazard Sticker 1 Radiation Safety Distance (13 m) Label
NOTE
When designing a mast, consider the minimum and maximum thickness of the mast plate marked on the
diagram. If the thickness of the mast plate is different from the recommended size (Min. 8.0mm/ Max. 10.0
mm), choose right sized bolts for mounting antenna on the mast according to the table below.
Mast Plate Thickness Recommended Bolt Size
8 ~ 13 mm M12 x 40L (Supplied)
13 ~ 18 mm M12 x 45L
18 ~ 23 mm M12 x 50L
