Specification
51
Chapter 9. Specification
9.1 Technical Specification
9.1.1 RF Specification
Item Specification
Rx Frequency Rx : 10.7 – 12.7 GHz
Rx Gain
(Wthout Radome)
Rx: 36.0 dBi
G/T
(@ 11.8 GHz, @ >30deg. EL)
12.2 dB/K
Tx Frequency Tx: 14.0 – 14.5 GHz
Tx Gain
(Without Radome)
Tx: 38.4dBi
EIRP
33.6 dBW / 20 MHz (single carrier)
36.6 dBW / 40 MHz (dual carrier)
Cross pol Isolation Min 20 dB (Antennas Field of view)
Polarization Rx: RHCP, Tx: LHCP
9.1.2 System Specification
Item Specification
Platform Three Axis: Azimuth, Elevation, Cross-level
Positioning 3-axis Velocity Mode Servo Control: Azimuth, Elevation, Cross-Level
Pedestal
Motion
Range
Azimuth -300° to +300°
Elevation -59° to +59° (FOV -53° to +53°)
Cross-Level -10° to +10°
Power Consumption
Primary: 76 W average, 80 W peak
Secondary: 76 W average, 80 W peak
Power Adaptor 300W Max
CNX Power Source AC/DC Adapter (Input 100-240 VAC, 50-60 Hz, Output 56 VDC)
DC Power to Antenna Subsystem Current 4 A average/ 5 A peak @ 32-60 V, 56 V nominal
